Description
Techdata sheet
Mode Phases/ THG ZQW-60/80/ 100/1 20/ 140/ 160/ 180/200 kW
| Lines | 3 phases+neutral+PE |
| Voltage | 380VAC±20% |
| Frequency | 50Hz±0% |
| Power | 60 / 80 / 100 / 120 / 140 / 160 / 180 / 200 |
| Volatge | 200-lOOOVDC |
| Current (max.) | CCS 2 200A,CHAdeMO 125A,GB/T 250A |
| Cable Lenth | Sm |
| Connector | CCS 2 or CHAdeMO or GB/T,Up to 2 charging guns |
| Power Factor | 0.99 |
| THD Value | 5% |
| Stable Voltage Accuracy | ±0.5% |
| Stable Current Accuracy | ±1% |
| Efficiency | 96% at nominal output power |
| Housing Material LED Indicator | Galvanized steel 7 inches |
| Emergency Stop Button | Mushroom headed type |
| Payment Method | RFID CARD |
| External | Ethernet, and 3G/4G |
| Communication Protocal | OCPP1.6J |
| Working Temperature | -30°C-+55°C |
| Working Altitude | 2000M |
| Application Site | Indoor/Outdoor |
| Cooling Method | Forced air cool |
| Multiple Protection | Over Current, Under Current, Over Voltage, Residual Current, Surge
Protection, Short Circuit, Earth Fault at input and output, Input Phase reversal, Emergency Shut-down with alarm, over temperature, Protection against electric shock. |
| Warranty | 1 year |
| Product Dimension | 550*650*1950mm(W* D*H) I 550*800*1950m m(W* D*H) |
| External Packing | Wooden case |
